Canon iR 2570С (0097B002)
Type Multifunctional
Maximum Original Size A3
Copy Sizes
Cassette: A5R - A3
Stack Bypass: A5 - SRA3 (320 x 457mm),
Resolution
Scanning: 600dpi x 600dpi
Copying: 600dpi x 600dpi
Printing: 240dpi equivalent x 600dpi
256 Graduations
Copy/Print Speed
A4: B/W: 31 ppm (iR3170C/Ci), 25 ppm (iR2570C/Ci)
A4: Full Colour: 7 ppm
A3: B/W: 16 ppm, Full Colour: 3.5 ppm
Magnification
Zoom: 25-400%
Fixed: 25%, 50%, 71%, 100%, 141%, 200%, 400%
First Copy Time
B/W: 8 sec
Full Colour: 23.9 sec
Warm-Up Time
6 minutes
Multiple Copies/Prints
1 - 999 sheets
Duplexing
Standard automatic stackless
Paper Weight
Cassette: 64 to 163gsm
Stack Bypass: 64 - 163gsm
Duplex: 64 - 105gsm
Cassette
Universal: A5R to A3, 305 x 457mm
Paper Capacity
Standard:
550 sheets x 2 cassettes (1100 sheets)
Multi Stack Bypass: 50 sheets (80gsm)
Optional:
550 x 2 cassettes (1100 sheets)
Paper deck: 2500 sheets
Total Paper capacity: 4,750 sheets
CPU
Canon Custom Processor, 533MHz + 400MHz
Memory
iR3170C/2570C: 512MB to 1024MB (optional)
iR3170Ci/2570Ci: 1024MB
Hard Disk Drive
80GB
Interface
Ethernet (100Base-TX/10Base-T) by USB
Power Supply
230V/6A/50Hz
Power Consumption
1.5kW maximum
Dimensions
565 (W) x 755 (D) x 754 (H) mm
Weight
86.2Kg
Network Printer Kit
Optional/Standard
Standard for iR3170Ci/2570Ci
Model Name
Colour Multi-PDL Printer Kit-D1
PDL
PCL5c, Postscript3 Emulation and UFR II
Resolution
2400 equivalent x 600dpi
Memory
1024MB (uses Main Unit RAM)
Hard Disk
80GB (uses Main Unit HDD)
CPU
Canon Custom Processor 533MHz & 400MHz
(uses Main Unit CPU)
PS Fonts
Roman136
PCL Fonts
Roman80, Bitmap1, Barcode30, OCR2
Supported OS
PCL: Windows 98/ME/NT4.0/2000/XP/2003
PS: Windows 98/ME/NT4.0/2000/XP/2003, Mac OSX (10.2 or later)
Mac-PPD: Mac OS8 or later
Interface
Ethernet (100Base-TX/10Base-T), USB
Network Protocol
TCP/IP (LPD/Port9100/IpPP/IPPS/SMB/FTP)
IPX/SPX (NDS, Bindery, NDPS-GW), AppleTalk
Pull Scan
Network TWAIN Driver
(75 - 600dpi 24bit color/ 8bit grayscale/Black & White)
Network Printer Kit
Model Name
Colour Network Printer Unit-F1
PDL
Adobe PostScript 3, PCL 5c
Resolution
2400 equivalent x 600dpi
Memory
128MB to 256MB (optional)
Hard Disk
20GB
CPU
Intel Mobile PentiumIII 850MHz
PS Fonts
Roman136
PCL Fonts
Roman113 (including Barcode Fonts)
Supported OS
PS: Windows 98/ME/NT4.0/2000/XP/2003, Mac OS9.0/ X (10.2, 10.3)
PCL: Windows 98/ME/NT4.0/2000/XP/2003
Interface
IEEE1284, Ethernet (100Base-TX, 10Base-T)
Network Protocol
TCP/IP (LPD/FTP/Port9100/IPP/SMB/email)
IPX/SPX (NDS, Bindery, NDPS-GW, AppleTalk
Universal Send Kit
Optional/Standard
Standard for the iR3170Ci/2570Ci
Model Name
Colour Universal Send Kit-D1
Scan speed
A4 44ipm 300dpi (Colour/ B&W) with DADF
Scan Resolution
100dpi, 150dpi, 200 x 100 dpi, 200dpi, 200 x 400 dpi, 300dpi, 400dpi, 600dpi
Destinations
E-Mail/ Internet FAX (SMTP), PC (SMB, FTP, NCP), iWDM
Address Book
LDAP, Local (Max. 1800)
File Format
Single: TIFF, JPEG, PDF
Multi: TIFF, PDF
PDF High Compression Kit
Model Name
PDF High Compression Kit-A1 (for Compression of Colour Scan Data)
Format
PDF
Resolution
300dpi
Cassette Feeding Unit
Model Name
Cassette Feeding Unit-Y2
Type
2 Front-loading adjustable drawers
Paper Weight
64 - 163gsm
Paper Capacity
550 sheets (80gsm) x 2 cassettes
Dimensions
565 (W) x 700 (D) x 251.5 (H) mm
Weight
Approx. 23kg
DADF
Model Name
DADF-L1
Paper Size
A3 - A5R
Paper Weight
Single sided original: 42 - 128gsm
Double sided original: 50 - 128gsm
Max. Number of Originals
50 sheets (80gsm)
Document Scanning Speed
Copy: A4 28ipm 600dpi (Colour / B&W)
Scan: A4 44 ipm 300dpi (Colour/ B&W)
Dimensions
565 (W) x 538 (D) x 122 (H) mm
Weight
Approx. 8.5kg
Paper Deck
Model Name
Paper Deck-Q1
Paper Size
A4
Paper Weight
64 - 105gsm
Paper Capacity
2,500 sheets (gsm)
Dimensions
372 (W) x 591 (H) x 473 (D) mm
Weight
Approx. 29.6kg
Finisher
Model Name
Finisher-P1
Number of Trays
One stack tray (Inner)
Tray Capacity
A4-A5R: 500 sheets
A3: 250 sheets
Staple Position
Corner, Double
Staple Capacity
A4: 50 sheets
A3: 30 sheets
Saddle Finisher
Model Name
Finisher-Q3/ Saddle Finisher-Q4
Number of Trays
2 trays (+ optional tray)
Tray Capacity
A4-A5R: 1000 sheets
A3: 500 sheets
Staple Position
Corner, Double, Saddle Stitch (Q4 only)
Staple Capacity
A4: 50 sheets
A3: 30 sheets
Saddle Stitch Specifications
(Saddle Finisher-Q4 only)
Paper size: A3, A4R
Staple capacity: 1 - 15 sheets (60 pages, 64-80gsm), 1 - 10 sheets (40 pages, 81-105gsm)
Paper weight: 64 - 105gsm (164m2 for Cover Sheet)
Dimensions: Q3: 536 x 657 x 1036mm, Q4: 648 x 657 x 1036mm
Weight: Q3: 39.6kg, Q4: 67.6kg
Other Accessories
Platen Cover-H, Inner 2-way Tray-C1, Buffer Pass, Unit-C1, Additional Finisher Tray-A1, Puncher Unit-L1/N1/P1, iR3100C pedestal, FL Cassette-Y1/Z1, Key Switch Unit-A2, DocumentTray-J1, Staple Cartridge-J1, Stamp Inc Cartridge-B1, Card Reader-C1, Card Reader Kit-B1, iR 512MB Expansion RAM-C1 (Standard for Ci Model), Super G3 FAX Board-S1, Universal Send PDF Encryption Kit-B1, Universal Send Searcheable PDF Kit-A1, Security Expansion Board-E1, iR Security Kit-A2, Web Access Software-A1, Remote Operator\'s Software Kit-A1, Barcode Printing Kit-A1,
